Astral Pool ECA Series Sand Filter

Astral ECA Media Filter

Astral ECA Sand Filters are Australian designed and made. The ECA Sand Filters suit small or medium-sized swimming pools and utilises the same high-quality manufacturing process as Astral Pools larger filters to achieve sparkling clear pool and spa water.

Features

• Injection Moulded High Strength Tank
• High Strength Materials for Long Life
• Suitable for In-Ground and Above Ground Pools
• 10 Year Warranty on Tank

 For further details http://www.astralpool.com.au/

Advice

Talk to the team at poolshop.com.au about your requirements; we help with replacement sand filters or sand filters for new pools. Please call us on 02 9970 5115 or Contact us, and we will happily answer any questions on sand filters.

Installation

Need installation? Call us on 02 9970 5115, and we will arrange the installation of sand filters in most areas across Australia.

Manual

Astral ECA Series Sand Filter Manual

Brochure

Astral ECA Series Sand Filter Brochure

Specifications

Model No.	ECA550	ECA650
Pool Coverage
6hr turnover	65,000 ltrs	92,000 ltrs
8hr turnover	85,000 ltrs	120,000 ltrs
Equipment
Tank diameter	540mm	630mm
Width (with valve installed)	55cm	65cm
Height (with valve installed)	95cm	103cm
Fine glass	3 bags	5 bags
Course glass	2 bags	3 bags
Sand required	80kg	120kg
Port size	40mm	40mm
Filter area	0.21 sq m	0.30 sq m
Shipping weight (with valve installed)	13kg	17kg
